Plastic Lumps Shredder Machine

Model	LDGB-600	LDGB-800	LDGB1000	LDGB-1200	LDGB-1500
Dimensions (mm)	2000*1300*2600	2000*1500*2800	2100*1700*2900	2200*1900*3200	2800*2350*3200
Inlet Size (mm)	600*500	800*600	1000*800	1200*1000	1500*1100
Tool Holder Diameter (mm)	420-550	420-550	420-630	420-800	420-630
Length of Blade Axis (mm)	600	800	1000	1200	1500
Rotary Speed (RPM)	550	550	550	550	550
Capacity(KG/H)	300-500	500-800	800-1200	1200-1500	2000-3500
Size of The Hole (mm)	12	12	12	12	12
Rotary Blade(PCS)	2X3	2X5	2X5	2X5	4X5
Fixed Blad(PCS)	2+2	2+2	2+2	2+2	3+3
Weight (KG)：	1800	3500	4800	7500	8500





Plastic block shredders are high-efficiency devices designed to crush large plastic materials into small pieces or granules. Widely used in the recycling industry, they process various plastic wastes like bottles, barrels, and sheets. The equipment features high-strength blades and an optimized power system for fast, uniform cutting. It has a robust structure, an easy-to-use control panel, and safety protection devices, ensuring user-friendly operation and safety.













High-Efficiency Cutting System
The plastic lump shredder features advanced blade designs and an optimized power transmission system, ensuring fast and uniform cutting results. For example, the LDGB-1500 model comes with a tool holder measuring 420-630mm in diameter and a 1500mm long blade shaft, capable of handling various large plastic wastes. This significantly boosts the machine's processing capacity while maintaining stability during continuous operation.



Robust and Durable Structure
All models employ high-strength materials and precise manufacturing techniques, guaranteeing stability and durability under intense working conditions. The LDGB-1500, weighing 8500kg, boasts a solid build that can withstand substantial impacts and vibrations, extending the equipment's lifespan.



User-Friendly Interface
Equipped with a simple control panel, the shredder allows operators to set up and use the machine with ease.



Convenient Maintenance and Care

Considering routine cleaning and maintenance needs, most parts of the shredder are designed for easy disassembly. Additionally, regular lubrication and inspections further prolong the machine's life and reduce malfunction rates.



Broad Application Range
Thanks to its powerful processing abilities and efficient performance, the plastic lump shredder is widely used in the recycling industry, handling diverse plastic wastes like bottles, drums, and sheets. This not only promotes resource recycling but also delivers significant economic benefits to businesses.





Plastic Recycling Industry
The plastic lump shredder plays a key role in the plastic recycling industry. It crushes large plastic waste into small pieces or granules, facilitating further processing and reuse. This process reduces waste volume and provides high-quality raw materials for recycled plastic products, promoting resource recycling and environmental protection.



Plastic Product Manufacturing
In the production of plastic products, some products or scraps inevitably do not meet standards. The plastic lump shredder crushes these waste materials for reintegration into the production line, reducing costs. This closed-loop production method maximizes resource utilization and significantly enhances economic efficiency.



Chemical Industry
Crushed plastic raw materials can be used in the production of chemical products, such as plastic additives and coatings. This application expands the use of plastic waste and adds value, offering an economical and efficient raw material solution for the chemical industry.



Construction Industry
The plastic lump shredder also mixes crushed plastic with other materials to create building insulation and soundproofing materials. These composite materials offer excellent performance and meet modern construction's environmental and energy-saving requirements, promoting the development of green building materials.





Own production factory & Source quality control Providing customized solutions & Professional technical R&D team

Efficient, safe and stable & First-line brand spare parts High quality production standards & International management and certification





Demand Analysis
Our professional sales team will communicate in-depth with you to understand your production needs, types of plastic raw materials, output requirements, etc., and provide the most suitable equipment selection suggestions.



Design
Based on your needs, we can tailor detailed crushing solutions for you, including equipment configuration, process flow, site layout, etc., ensuring the equipment integrates perfectly into your production system.



Site Inspection
If needed, we can arrange for our technicians to visit your site to understand the actual situation and provide more accurate solutions and suggestions.



Cost Budget
We will provide you with a detailed equipment quotation and operating cost budget, so you can clearly understand the investment costs and expected benefits to make informed decisions.





Installation and Testing

Our professional and technical personnel will install and test the equipment for you free of charge to ensure its normal operation.



Training Guidance

We will provide comprehensive training for your operators, covering equipment operation, maintenance, troubleshooting, and other aspects, to ensure they can master the use of the equipment.



Regular Follow-up Visits

Our after-sales personnel will make regular visits to understand the operation of the equipment and provide you with necessary technical support and maintenance suggestions.



Spare Parts Supply

We will provide the original equipment parts required for a long time to ensure that you can replace them promptly and reduce equipment downtime.



Fault Maintenance

Upon receiving your fault repair report, we will respond quickly and arrange for technicians to conduct on-site maintenance in a timely manner to ensure that the equipment resumes normal operation as soon as possible.
